NARDA FieldMan User Manual

8 Operating modes
60 FieldMan Narda
8.2 FIELD STRENGTH
The FIELD STRENGTH operating mode is used to measure the field strength or flux den-
sity and enables the numerical display of the measurement results for a defined fre-
quency range. This frequency range can be broadband or band-limited. A time curve
(Time Curve) can be activated as a rolling memory for the measurement results.
This is the most commonly used mode for broadband or band-limited meas
urements.
8.2.1 Measurement settings
The MEASUREMENT SETTINGS menu provides quick access to the most important
measurement settings for the selected operating mode.
Function
1)
Description
Reset Results Reset measurement results
Zero Offset correction (HP-01 probe only)
⇒ See 10.3 Offset correction – Zero on page 102.
Frequency Span Frequency range
Field Electric or magnetic field
Range Measuring range
Unit Unit
Low Cut Filter Filter for suppression of low frequencies (low cut filter)
Detector Detector type
Time Curve Show/hide time curve display
Time Span Timeline for time curve display
Single Run Automatic stop of the measuring sequence
(only visible if Time Curve = On)
Pulse Detection Short integration time for HF measurement, e.g. for more
accurate measurement of short radar pulses (only visible
with suitable HF probes)
Averaging Time Time for moving averaging
1) The available parameters depend on the selected operating mode and the connected probe
type.
