8.2 FIELD STRENGTH
Narda FieldMan 61
8.2.2 Numerical display
Two fields are available for numerical display:
• Main field: Displays current or static measured values depending on the selected
result type and detection type
• Supplementary field: Always displays static values
Detector
Select a detector:
⇒ MEASUREMENT SETTINGS: Select a detector under Detector.
↳ The selection option depends on the probe used:
Detector Description Availability
RMS All measured values are recorded and displayed
as RMS values.
All probes
Peak All measured values are recorded and displayed
as peak values.
BFD-400-1
probe only
Result type
The result types are always displayed in the supplementary field. To display them in the
main field, the result type must be selected in the selection field using the cross key.
Select a result type:
⇒ Press the ◄ ► keys repeatedly until the desired result type is displayed.
↳ The selection option depends on the selected detector:
Detector Result types Display in supple-
mentary field
Evaluation
RMS ACTUAL - Current measured value
MINIMUM MIN Smallest value
MAXIMUM MAX Highest value
AVERAGE AVG Averaged value
MAX AVERAGE MAXAVG Highest averaged value
Peak ACTUAL - Current measured value
MINIMUM MIN Smallest peak value
MAXIMUM MAX Highest peak value
