VS1 Operations and Maintenance Manual Routine maintenance
Page 3-6 Issue 3.1 2013-10-01
Meter Parameter
(displayed on front panel UI
or remote AUI
Meter Value at ...
88 MHz 98 MHz 108 MHz
Delta 10 MHz
N/A N/A N/A
IPA Fwd
63.7 W 74.9 W 79.6 W
Total PA Curr
42.1 A 42.0 A 41.7 A
DC Power In
1697 W 1736 W 1794 W
DC-RF Eff
73.2 % 71.9 % 69.4 %
Avg PA Diss
101 W 110 W 125 W
PA1 Bias
0.00 V 0.00 V 0.00 V
PA2 Bias
0.00 V 0.00 V 0.00 V
PA3 Bias
0.00 V 0.00 V 0.00 V
PA4 Bias
0.00 V 0.00 V 0.00 V
IPA Bias
2.74 V 2.74 V 2.74 V
Preamp Bias
2.81 V 2.81 V 2.81 V
Fwd Atten
10.0 dB 10.0 dB 10.0 dB
DAC Gain
99.7 % 90.6 % 88.9 %
