VS1 Operations and Maintenance Manual Operating the transmitter
Issue 3.1 2013-10-01 Page 2-101
System Settings - Front Panel UI
You can establish calibration values and fault thresholds for critical parameters of the VS1 using the
remote AUI or using the local front panel display. The following options are available:
• Configuring ARM Watchdog - see page 2-102
• Calibrating Exciter TCXO - Using the front panel - see page 2-100
• Configuring RF drive source - see page 2-103
• ARM Reset - see page 2-103
• OS Recovery - see page 2-104
• Firmware Update - see page 2-105
• FM Polarity - see page 2-105
WARNING:
System settings are established at Nautel and should not require any
adjustment. Making changes to these settings may void your warranty.
Contact Nautel before making changes.
Note: :
Changing threshold values in the front panel UI’s System Settings -> Thresholds menu and
changing the console selection in the System Settings -> Console Select menu is not normally
required, and should only be performed by trained personnel. Information on these sub-menus is
not included in the manual. Contact Nautel for assistance.
