VS1 Operations and Maintenance Manual Operating the transmitter
Issue 3.1 2013-10-01 Page 2-133
User Settings - Front Panel UI
You can establish various user settings for the VS1 using the local front panel display. The following
options are available:
• Setting Pilot Sample Level
• LCD Settings - see page 2-134
• Signal Generator - see page 2-136
• Setting Station ID parameters - see page 2-138
• Selecting FM Mask - see page 2-140
• Setting Audio Low Thresholds - see page 2-140
• Turn-On Delay Setting - see page 2-142
• Ramp-Up Speed Setting - see page 2-142
Setting Pilot Sample Level
From the front panel UI, you can set the level of the pilot sample that is applied to the PILOT SAMPLE
OUT (A1J4A)
BNC connector on the rear of the controller (A4). To view the Pilot Sample screen,
select User Settings -> Pilot Sample from the Main Menu (see Figure 2.117 on page 2-134).
Note:
The following Front Panel User Settings are detailed in their corresponding remote AUI or stand
alone sections: Edit Presets, Remote I/O, Set Clock, Network Settings, Ext. 10MHz and
Audio Processor.
Note:
Setting the pilot sample is only available using the front panel display.
