Chapter 5: Communications 7197 Owner’s Guide
February 2002
62
Using BASIC to Send Commands
In BASIC, printer commands are sent as a string of characters preceded by the LPRINT
command. For example,
LPRINT CHR$(&H0A)
sends the hexadecimal number 0A to the printer, which causes the printer to print the
contents of its print buffer. Previously sent commands tell the printer exactly how this data
should appear on the paper. For example,
LPRINT CHR$(&H12); "ABC"; CHR$(&H0A)
sends the Hex numbers 12 41 42 43 0A to the printer. This causes the printer to set itself to
double wide mode (12), load the print buffer with “ABC” (41 42 43), and finally, print (0A).
Again, the communication link that the BASIC program outputs to must be matched to
that of the printer.
RS-232C Interface
The RS-232C interface uses either XON/XOFF or DTR/DSR protocol. For XON/XOFF, a
particular character is sent back and forth between the host and the printer to regulate the
communication. For DTR/DSR, changes in the DTR/DSR signal coordinate the data flow.
The RS-232C version of the 7197 offers the standard options which are selectable in the
Diagnostic mode. See “Diagnostics: Communications Interface Settings” later in this book.
Print Speed and Timing
The fast speed of the printer requires the application to send data to the printer at least as
fast as it is printed. This application must also allow receipt lines to be buffered ahead at
the printer, so the printer can print each line immediately after the preceding line, without
stopping to wait for more data. Ideally, the application will send all the data for an entire
receipt without pausing between characters or lines transmitted.
If the application sends data at 9600 baud and pauses between lines for as little as 50
milliseconds, the printer will never be able to print at full speed. But, if the application
sends data at 19.2 K baud and does not pause between lines, the printer will be able to
print at its full speed of 1020 lines/minute.
The table shows that with a pause of 50 milliseconds after each line, the transmit time
equals or exceeds the print time, slowing down the printer, regardless of the baud rate.
Char./Line Lines/Receipt Transmit Time: (9600 Baud) Transmit Time: (19.2 K Baud) Print Time
20 20 1.4 Seconds 1.2 Seconds 1.2 Seconds
20 40 2.8 Seconds 2.4 Seconds 2.4 Seconds
44 20 1.88 Seconds 1.44 Seconds 1.2 Seconds
44 40 3.76 Seconds 2.88 Seconds 2.4 Seconds
The next table shows that with no delay between lines, the transmit time is much less than
the print time, allowing the printer to print at full speed.
Char./Line Lines/Receipt Transmit Time: (9600 Baud) Transmit Time: (19.2 K Baud) Print Time
20 20 0.4 Seconds 0.2 Seconds 1.2 Seconds
20 40 0.8 Seconds 0.4 Seconds 2.4 Seconds
44 20 0.88 Seconds 0.44 Seconds 1.2 Seconds
44 40 1.76 Seconds 0.88 Seconds 2.4 Seconds
