73
LCD Menu
(If you selected Image Orient)
← Displays the currently selected item with asterisk (*).
← Displays the setting.
Normal-F Front projection. With the projector installed on the pedestal, projection is executed from the front
of the screen.
Normal-R Rear projection. With the projector installed on the pedestal, projection is executed from the
back of the screen.
UpsideDown-F Ceiling front projection. With the projector installed on the ceiling, projection is executed from the
front of the screen.
UpsideDown-R Ceiling rear projection. With the projector installed on the ceiling, projection is executed from the
back of the screen.
(If you selected Fan Tilt Setting)
← Displays the currently selected item with asterisk (*).
← Displays the setting.
Floor Select when the projector is installed on a desktop.
Ceiling Select when the projector is installed on the ceiling.
Lens Center
To move the lens shift to the center position. The center position may slightly shift depending upon mounting conditions of the
lens.
← Press the ENTER button to execute moving.
Baudrate
To select the transmission speed (bps) for your projector (SYSTEM) and a PC when they are connected by a commercially
available RS-232C straight cable. Select one from 4800, 9600, 19200 and 38400. Select the transfer speed corresponding to
the speed of the connected devices.
← Displays the currently selected item with asterisk (*).
← Displays the setting.
