Adding and Removing Components 3-19
14. Push in on the ejector until the power supply is firmly seated in the chassis.
See Figure 3-27.
Figure 3-27. Closing the Power Supply Ejector.
15. Secure the ejector with the set screw. See Figure 3-28.
Figure 3-28. Securing the Power Supply Ejector.
16. Plug the power cord in the connector on the power supply, and secure the
power cord with the power cord retainer clip. Turn on the power switch.
