Chapter 8 Disk Array Configuration Setting (S100/S1100/S1200/S1300/S2100/S2200/S2300)
IV-147
(2) Operation
In this dialog, RANK Bind/unbind can be performed by using the popup menu of the right button or the buttons
on the screen after selecting PDs and RANKs, etc. The encircled alphabets on the screen are described.
Figure 8-43 RANK/Spare Tab Screen Menu and Buttons
(A) Unselect
Deselects the selected RANKs, unused PDs or Spares.
Popup Menu
(A)
(B)
(C)
To Next Page
