(9) Remote wake-up control register (REMWUP)
This register transmits the Resume signal to perform remote wakeup.
Remote wakeup must be performed after confirming that bus idle has continued longer than 5 ms.
REMWUP is set with a 1-bit or 8-bit memory manipulation instruction.
RESET input sets REMWUP to 08H.
Figure 8-19. Format of Remote Wakeup Control Register
Symbol 67 5 4 <3> <2> <1> <0>
0 0 0 0 PULLDM PULLDP PULLEN WAKEUP
PULLDM D- lead low/high fixed output setting
0
1
FF6AH
Address
REMWUP
After reset
08H
R/W
R/W
D- (TXDM) is fixed to low output.
D- (TXDM) is fixed to high output.
PULLDP D+ lead low/high fixed output setting
0
1
D+ (TXDP) is fixed to low output.
D+ (TXDP) is fixed to high output.
PULLEN D+/D- lead fixed output enable
0
1
Output from transmit buffer is input to USB driver.
Level set to PULLDP or PULLDM is input to USB driver.
WAKEUP Wakeup signal output
0
1
No data is sent.
Pin status set to PULLDP or PULLDM is output.
