CHAPTER 6 8-BIT TIMER/EVENT COUNTERS 00 AND 01

User’s Manual U12978EJ3V0UD

(3) Port mode register 2 (PM2)

This register sets port 2 input/output in 1-bit units.

When using the P26/TO01/INTP0/TI01 pin for timer output, set P26 and the output latch of P26 to 0.

When P26/TO01/INTP0/TI01 pin is used as a timer input, set PM26 to 1.

PM2 is set by a 1-bit or 8-bit memory manipulation instruction.

RESET input sets PM2 to FFH.

Figure 6-5. Format of Port Mode Register 2

PM26

1 PM26 PM25 PM24 PM23 PM22 PM21 PM20PM2

7654

R/W

3210

Input mode (output buffer off)

Symbol

Address

FF22H FFH

After reset

P26 pin input/output mode selection

Output mode (output buffer on)
