CHAPTER 3 CPU ARCHITECTURE

User’s Manual U12978EJ3V0UD

3.4.3 Special function register (SFR) addressing

[Function]

The memory-mapped special function register (SFR) is addressed with 8-bit immediate data in an instruction

word.

This addressing is applied to the 240-byte spaces FF00H to FFCFH and FFE0H to FFFFH. However, the

SFR mapped at FF00H to FF1FH can be accessed with short direct addressing.

[Operand format]

Identifier Description

sfr Special function register name

[Description example]

MOV PM0, A; When selecting PM0 for sfr

Instruction code 11100111

00100000

[Illustration]

SFR

Effective

Address

111111

Opcode

sfr-offset
