APPENDIX A DEVELOPMENT TOOLS
User’s Manual U12978EJ3V0UD
225
A.5 Debugging Tools (Hardware)
IE-78K0S-NS
In-circuit emulator
In-circuit emulator for debugging hardware and software of an application system using the
78K/0S Series. Supports a integrated debugger (ID78K0S-NS). Used in combination with an
AC adapter, emulation probe, and interface adapter for connecting the host machine.
IE-78K0S-NS-A
In-circuit emulator
The IE-78K0S-NS-A provides a coverage function in addition to the IE-78K0S-NS functions, thus
enhancing the debug functions, including the tracer and timer functions.
IE-70000-MC-PS-B
AC adapter
Adapter for supplying power from an AC 100 to 240 V outlet.
IE-70000-98-IF-C
Interface adapter
Adapter necessary when using PC-9800 series PC (except notebook type) as host machine (C
bus supported)
IE-70000-CD-IF-A
PC card interface
PC card and interface cable necessary when using notebook PC as host machine (PCMCIA
socket supported)
IE-70000-PC-IF-C
Interface adapter
Interface adapter necessary when using IBM PC/AT compatible as host machine (ISA bus
supported)
IE-70000-PCI-IF-A
Interface adapter
Adapter necessary when using personal computer incorporating PCI bus as host machine
IE-789801-NS-EM1
Emulation board
Board for emulating the peripheral hardware inherent to the device. Used in combination with an
in-circuit emulator.
NP-44GB-TQ
NP-H44GB-TQ
Emulation probe
Cable to connect the in-circuit emulator and target system.
Used in combination with the TGB-044SAP.
TGB-044SAP
Conversion
adapter
Conversion adapter to connect the NP-44GB-TQ or NP-H44GB-TQ and a target system board
on which a 44-pin plastic LQFP (GB-8ES type) can be mounted
Remarks 1. The NP-44GB-TQ and NP-H44GB-TQ are products made by Naito Densei Machida Mfg. Co., Ltd.
(TEL +81-45-475-4191).
2. The TGB-044SAP is a product made by TOKYO ELETECH CORPORATION.
For further information, contact: Daimaru Kogyo, Ltd.
Tokyo Electronics Department (TEL +81-3-3820-7112)
Osaka Electronics Department (TEL +81-6-6244-6672)
