CHAPTER 8 USB FUNCTION

User’s Manual U12978EJ3V0UD

147

8.8.2 Receive bank switching ID detection buffer operation

Figure 8-26. Flowchart of Receive Bank Switching ID Detection Buffer Operation

01B

00B

Idle state

2-bit store & shift

1-bit store & shift

Set buffer to 00H

Bit judgment enable

Set TOSTAT

Bit judgment mask

Sync1 detection

signal = 1?

EOP received?

Store bit ?

Set DASTAT

Set HSSTAT

11B 10B

TOSTAT: Bit 0 of packet receive status register (RXSTAT)

DASTAT: Bit 1 of packet receive status register (RXSTAT)

HSSTAT: Bit 2 of packet receive status register (RXSTAT)
