CHAPTER 8 USB FUNCTION

User’s Manual U12978EJ3V0UD

144

Figure 8-25. Flowchart of Transmit/Receive Pointer Operation (5/7)

(3) Data packet transmit (1/2)

Transmit buffer

Handshake

Idle state

Set USBPOW to 7FH

USBPOB increment

Set USBPOW to n0H

Set USBPOB to 00H

Bit read

Transmit/receive

signal?

Does bit stuffing

signal = 1?

USBPOB

overflow?

USBPOW

= n1H?

Transmit area?

(reservation flag

judgment)

USBPOB

overflow?

USBPOB increment

USBPOW increment

Bit Read

Does bit stuffing

signal = 1?

Does

USBPOW match

DTXCOm?

Data/handshake transmission

Set CRC16 execution

start signal

Go to (4)

n = 2: Transmit buffer 0

n = 3: Transmit buffer 1

m = 0: send buffer 0

m = 1: send buffer 1

DTXCO0, DTXCO1: Data packet transmit byte number counter
