User’s Manual U12978EJ3V0UD
18
LIST OF FIGURES (4/4)
Figure No. Title Page
14-3 Example of Connection with Dedicated Flash Programmer ................................................................... 193
14-4 VPP
Pin Connection Example.................................................................................................................. 195
14-5 Signal Conflict (Input Pin of Serial Interface)..........................................................................................196
14-6 Abnormal Operation of Other Device...................................................................................................... 196
14-7 Signal Conflict (RESET Pin) ................................................................................................................... 197
14-8 Wiring Example for Flash Writing Adapter with 3-Wire Serial I/O...........................................................198
14-9 Wiring Example for Flash Writing Adapter with Pseudo-3-Wire Method ................................................199
A-1 Development Tools.................................................................................................................................222
A-2 Distance Between In-Circuit Emulator and Conversion Adapter ............................................................ 227
A-3 Connection Condition of Target System (NP-H44GB-TQ)......................................................................228
