E2600 Controller-Drive Tray Installation Guide 124
Operational error OE+ Lx+ Lock-down codes. (See Things to Know –
Lock-Down Codes for the Controller-Drive
Tray on page 125.)
Operational state OS+
OL+ = Offline.
bb+ = Battery backup (operating on
batteries).
OH + CPU temperature exceeds the
warning level.
CF+ = Component failure.
Component failure CF+
dx+ = Processor or cache DIMM.
Cx = Cache DIMM.
Px+ = Processor DIMM.
Hx+ = Host interface card.
Fx+ = Flash drive.
bl + Base Controller Card
Diagnostic failure dE+ Lx+ = Lock-down codes (See Things to Know
– Lock-Down Codes for the Controller-Drive
Tray on page 125 and Things to Know –
Seven-Segment Display Use Cases on page
126.)
Category delimiter dash+ The separator between category-detail code
pairs is used when more than one category
detail code pair exists in the sequence.
End-of-sequence
delimiter
blank -
(See Note
4)
The end-of-sequence delimiter is automatically
inserted by the hardware at the end of a code
sequence.
Notes:
1 A two-digit code that starts a dynamic display sequence.
2 A two-digit code that follows the category code with more specific information.
3 The plus (+) sign indicates that a two-digit code displays with the Diagnostic
LED on.
4 No codes display, and the Diagnostic LED is off.
