E2600 Controller-Drive Tray Installation Guide 127
Failed flash drive OS+ CF+ Fx+ blank-
Use Cases Repeating Sequence
Use Case: Power-on diagnostic failure
A component that is not a field replaceable unit
failure has been detected.
SE+ dF+ blank-
A processor DIMM failure has been detected. SE+ dF+ dash+ CF+ Px +
blank-
A cache memory DIMM failure has been detected. SE+ dF+ dash+ CF+ Cx +
blank-
A processor DIMM or a cache memory DIMM failure
has been detected.
SE+ dF+ dash+ CF+ dx +
blank-
A host interface card failure has been detected. SE+ dF+ dash+ CF+ Hx +
blank-
An incorrect number of cache backup devices have
been detected.
SE+ LC+ dash+ CF+ Fx +
blank-
Use Cases Repeating Sequence
Use Case: Controller is suspended and there are no other
errors to report.
All lockdown conditions OH+ Lx+ blank-
Use Cases Repeating Sequence
Use Case: The controller is suspended because of
component errors.
Persistent processor DIMM error correcting code
(ECC) errors have been detected.
OE+ L2+ dash+ CF+ CX+
blank-
Persistent cache DIMM ECC errors have been
detected.
OE+ L2+ dash+ CF+ CX+
blank-
Persistent processor or cache DIMM ECC errors have
been detected.
OE+ L2+ dash+ CF+ CX+
blank-
Use Cases Repeating Sequence
Use Case: The controller has been suspended as a result of
persistent cache backup configuration errors.
The write-protect switch is set during cache restore. OE+ LC+ blank-
Use Cases Repeating Sequence
