E2600 Controller-Drive Tray Installation Guide 129
H1 An SFP transceiver speed mismatch (a 2-Gb/s SFP
transceiver is installed when the drive tray is operating at 4
Gb/s) indicates that an SFP transceiver must be replaced.
Look for the SFP transceiver with a blinking amber LED.
H2 The ESM configuration is invalid or incomplete, and it
operates in a Degraded state.
H3 The maximum number of ESM reboot attempts has been
exceeded.
H4 This ESM cannot communicate with the alternate ESM.
H5 A midplane harness failure has been detected in the drive
tray.
H6 An ESM firmware failure has been detected.
H8 SFP transceivers are present in currently unsupported ESM
slots, either 2A or 2B. Secondary trunking SFP transceiver
slots 2A and 2B are not supported. Look for the SFP
transceiver with the blinking amber LED, and remove it.
H9 A non-catastrophic hardware failure has occurred. The ESM
is operating in a Degraded state.
J0 The ESM canister is incompatible with the drive tray
firmware.
Diagnostic Code Description
