Virtual Private Networking
104
N300 Wireless ADSL2+ Modem Router DGN2200v3
Overview of VPN Configuration
Two common scenarios for VPN tunnels are between a remote PC and a network gateway;
and between two or more network gateways. The DGN2200v3 supports both types. The
DGN2200v3 supports up to five concurrent tunnels.
Client-to-Gateway VPN Tunnels
Client-to-gateway VPN tunnels provide secure access from a remote PC, such as a
telecommuter connecting to an office network.
N300 Wireless Modem Router
DGN2200
VPN tunnel
Internet
PC running NETGEAR
ProSafe VPN Client
Figure 9. Telecommuter VPN tunnel
A VPN client access allows a remote PC to connect to your network from any location on the
Internet. The remote PC is one tunnel endpoint, running the VPN client software. The modem
router on your network is the other tunnel endpoint. (See Set Up a Client-to-Gateway VPN
Configuration on page 107.)
Gateway-to-Gateway VPN Tunnels
Gateway-to-gateway VPN tunnels provide secure access between networks, such as a
branch or home office and a main office.
Gateway A (Home)
Gateway B
VPN tunnel
Internet
(Office)
N300 Wireless Modem Router
DGN2200
Figure 10. VPN tunnel between networks
