Supplemental Information
145
N300 Wireless ADSL2+ Modem Router DGN2200v3
Specifications
Specification Description
Network protocol and
standards compatibility
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE or PPPoA, RFC 1483 Bridged or
Routed Ethernet, and RFC 1577 Classical IP over
ATM
Power adapter North America: 120V, 60 Hz, input
UK, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
All regions (output): 12V @ 1A output
Physical Dimensions: 6.80 in. x 5.03 in. x 1.28 in. (173 mm x 128 mm x 33 mm)
Weight: 0.65 lbs. without the stand (0.29 kg)
Environmental Operating temperature: 0° to 40° C (32º to 104º F)
Operating humidity: 10% to 90% relative humidity, noncondensing
Storage temperature: –20° to 70° C (–4º to 158º F)
Storage humidity: 5 to 95% relative humidity, noncondensing
Regulatory compliance FCC Part 15 Class B; VCCI Class B; EN 55 022 (CISPR 22), Class B
Network protocol and
standards compatibility
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE or PPPoA, RFC 1483 Bridged or
Routed Ethernet, and RFC 1577 Classical IP over
ATM
Power adapter North America: 120V, 60 Hz, input
Regulatory compliance FCC Part 15 Class B; VCCI Class B; EN 55 022 (CISPR 22), Class B
Interface specifications LAN: 10BASE-T or 100BASE-Tx, RJ-45
WAN: ADSL, Dual RJ-11, pins 2 and 3
T1.413, G.DMT, G.Lite
ITU Annex A hardware or Annex B hardware
ITU G.992.5 (ADSL2+)
