Advanced Settings
97
N300 Wireless ADSL2+ Modem Router DGN2200v3
In this case you have to define a static route, telling your modem router that 134.177.0.0
should be accessed through the ISDN modem router at 192.168.1.100. In this example:
• The Destination IP Address and IP Subnet Mask fields specify that this static route
applies to all 134.177.x.x addresses.
• The Gateway IP
Address field specifies that all traffic for these addresses should be
forwarded to the ISDN modem router at 192.168.1.100.
• A metric value of 1 will work since the ISDN modem router is on the LAN.
• Private is selected only as a precautionary security measure in case RIP is activated.
To set up a static route:
1. Select Advanced >
Advanced Setup > Static Routes.
2. Click Add to display the following screen:
3. In the Route Name field, type a name for this static route (for identification purposes only.)
4. Select the Private check box if you want to limit access to the LAN only
. If Private is
selected, the static route is not reported in RIP.
5. Select the Active check box to make this route ef
fective.
6. T
ype the destination IP address of the final destination.
7. T
ype the IP subnet mask for this destination. If the destination is a single host, type
255.255.255.255.
8. T
ype the gateway IP address, which has to be a modem router on the same LAN segment
as the N300 Wireless ADSL2+ Modem Router.
9. T
ype a number from 1 through 15 as the metric value.
This value represents the number of modem routers between your network and the
destination. Usually
, a setting of 2 or 3 works, but if this is a direct connection, set it to 1.
10. Click Apply to add the static route.
