NETGEAR FVS318 - ProSafe VPN Firewall Router User Manual

Reference Manual for the ProSafe VPN Firewall FVS318v3
7-2 Maintenance
January 2005
This screen shows the following parameters:
Table 7-1. FVS318v3 Status fields
Field Description
System Name The System Name assigned to the firewall.
Firmware Version The firewall firmware version.
WAN Port These parameters apply to the Internet (WAN) port of the firewall.
MAC Address The MAC address used by the Internet (WAN) port of the firewall.
IP Address The IP address used by the Internet (WAN) port of the firewall. If no address is
shown, the firewall cannot connect to the Internet.
IP Subnet Mask The IP Subnet Mask being used by the Internet (WAN) port of the firewall.
DHCP The protocol on the WAN port used to obtain the WAN IP address. This field can
show DHCP Client, Fixed IP, PPPoE, BPA or PPTP. For example, if set to Client,
the firewall is configured to obtain an IP address dynamically from the ISP.
LAN Port These parameters apply to the Local (WAN) port of the firewall.
MAC Address The MAC address used by the LAN port of the firewall.
IP Address The IP address used by the Local (LAN) port of the firewall. The default is
192.168.0.1
IP Subnet Mask The IP Subnet Mask used by the Local (LAN) port of the firewall. The default is
255.255.255.0
DHCP Identifies if the firewall’s built-in DHCP server is active for the LAN attached
devices.

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
