Reference Manual for the ProSafe VPN Firewall FVS318v3
VPN Configuration of NETGEAR FVS318v3 E-5
January 2005
Activating the VPN Tunnel
You can activate the VPN tunnel by testing connectivity and viewing the VPN tunnel status
information as described in the following flowchart:
Figure E-4: Testing Flowchart
All traffic from the range of LAN IP addresses specified on the router at Gateway A and the router
at Gateway B will now flow over a secure VPN tunnel.
Test Step 1
Ping Remote
LAN IP Address
Test Step 2
Ping Remote
WAN IP Address
Test Step 3
View VPN
Tunnel Status
Start
Fix the
Router Network
Fix the
VPN Tunnel
End
Fail Pass
Fail Pass
and then Retest and then Retest

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
