Reference Manual for the ProSafe VPN Firewall FVS318v3
E-20 VPN Configuration of NETGEAR FVS318v3
January 2005
The FVS318v3-to-FVL328 Case
Configuring the VPN Tunnel
Note: This scenario assumes all ports are open on the FVS318v3 and FVL328.
Figure E-14: LAN to LAN VPN access from an FVS318v3 to an FVL328
Use this scenario illustration and configuration screens as a model to build your configuration.
1. Log in to the FVS318v3 labeled Gateway A as in the illustration (Figure E-14).
Log in at the default address of http://192.168.0.1 with the default user name of admin and
default password of password (or using whatever password and LAN address you have
chosen).
Table E-3. Policy Summary
VPN Consortium Scenario: Scenario 1
Type of VPN LAN-to-LAN or Gateway-to-Gateway
Security Scheme: IKE with Preshared Secret/Key
Date Tested: November 2004
Model/Firmware Tested:
NETGEAR-Gateway A FVS318v3 with firmware version v3.0_14
NETGEAR-Gateway B FVL328 with firmware version V2.0_01
IP Addressing:
NETGEAR-Gateway A Static IP address
NETGEAR-Gateway B Static IP address
FVL328
Gateway B
Scenario 1
14.15.16.17 22.23.24.25
WAN IP
WAN IP
172.23.9.1/2410.5.6.1/24
LAN IP
LAN IP
Gateway A
FVS318v3
