NETGEAR FVS318 - ProSafe VPN Firewall Router User Manual

Reference Manual for the ProSafe VPN Firewall FVS318v3
Connecting the Firewall to the Internet 3-9
January 2005
How to Log On to the FVS318v3 After
Configuration Settings Have Been Applied
1. Connect to the VPN firewall router by typing http://www.routerlogin.net in the address field
of your browser, then press Enter.
Figure 3-7: Login URL
2.
For security reasons, the firewall has its own user name and password. When prompted, enter
admin for the firewall user name and password for the firewall password, both in lower case
letters. To change the password, see “Changing the Administrator Password” on page 7-8
Note: The firewall user name and password are not the same as any user name or password
you may use to log in to your Internet connection.
A login window like the one shown below opens:
Figure 3-8: Login window
Once you have entered your user name and password, your Web browser should find the
FVS318v3 VPN Firewall and display the home page as shown below.

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
