Reference Manual for the ProSafe VPN Firewall FVS318v3
2-6 Introduction
January 2005
The FVS318v3 Rear Panel
The rear panel of the FVS318v3 VPN Firewall contains the port connections listed below.
Figure 2-2: FVS318v3 rear panel
Viewed from left to right, the rear panel contains the following features:
• Factory default reset push button
• Eight Ethernet LAN ports
• Internet Ethernet WAN port for connecting the firewall to a cable or DSL modem
Table 2-1. LED Descriptions
LED Label Activity Description
PWR On Power is supplied to the firewall.
TEST On
Off
The system is initializing.
The system is ready and running.
INTERNET
100 (100 Mbps) On
Off
The Internet (WAN) port is operating at 100 Mbps.
The Internet (WAN) port is operating at 10 Mbps.
LINK/ACT
(Link/Activity)
On
Blinking
The Internet port has detected a link with an attached device.
Data is being transmitted or received by the Internet port.
LOCAL
100 (100 Mbps) On
Off
The Local port is operating at 100 Mbps.
The Local port is operating at 10 Mbps.
LINK/ACT
(Link/Activity)
On
Blinking
The Local port has detected a link with an attached device.
Data is being transmitted or received by the Local port.
FACTORY DEFAULTS
Reset Button
ON/OFF
Switch
DC PowerINTERNET
Port
LOCAL
Ports

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
