Reference Manual for the ProSafe VPN Firewall FVS318v3
Basic Virtual Private Networking 5-21
January 2005
Procedure to Configure a Gateway-to-Gateway VPN Tunnel
Follow this procedure to configure a gateway-to-gateway VPN tunnel using the VPN Wizard.
1. Log in to the FVS318v3 on LAN A at its default LAN address of http://192.168.0.1 with its
default user name of
admin and password of password. Click the VPN Wizard link in the
main menu to display this screen. Click Next to proceed.
Figure 5-23: VPN Wizard start screen
2.
Fill in the Connection Name and the pre-shared key, select the type of target end point, and
click Next to proceed.
Figure 5-24: Connection Name and Remote IP Type
Enter the new Connection Name:
(GtoG in this example)
Enter the pre-shared key:
(12345678 in this example)
Select the radio button:
A remote VPN Gateway

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
