Reference Manual for the ProSafe VPN Firewall FVS318v3
3-4 Connecting the Firewall to the Internet
January 2005
Figure 3-4: Status lights
d.
Check the VPN firewall router status lights to verify the following:
• PWR: The power light should turn solid green. If it does not, see “Troubleshooting
Tips” on page 3-6.
• TEST: The test light blinks when the firewall is first turned on then goes off. If after
two minutes it is still on, see “Troubleshooting Tips” on page 3-6.
• INTERNET: The Internet LINK light should be lit. If not, make sure the Ethernet cable
is securely attached to the VPN firewall router Internet port and the modem, and the
modem is powered on.
• LOCAL: A LOCAL light should be lit. Green on the 100 line indicates your computer
is communicating at 100 Mbps; off on the 100 line indicates 10 Mbps. If a LOCAL
light is not lit, check that the Ethernet cable from the computer to the firewall is
securely attached at both ends, and that the computer is turned on.
Now, Configure the FVS318v3 for Internet Access
1. From the Ethernet connected PC you just set up, open a browser such as Internet Explorer or
Netscape® Navigator.
Power Internet Local Port 8Test

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
