NETGEAR FVS318 - ProSafe VPN Firewall Router User Manual

Reference Manual for the ProSafe VPN Firewall FVS318v3
E-4 VPN Configuration of NETGEAR FVS318v3
January 2005
Figure E-3: NETGEAR’s VPN Wizard for the router at a gateway A (part 2 of 2)
Note: The default log in address for the FVS318v3 router is http://192.168.0.1 with the
default user name of admin and default password of password. The login address will
change to the local LAN IP subnet address after you configure the router. The user name
and password will also change to the ones you have chosen to use in your installation.
Step 5: Verify the information
(example screen)
Example screen

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
