Reference Manual for the ProSafe VPN Firewall FVS318v3
E-38 VPN Configuration of NETGEAR FVS318v3
January 2005
Figure E-28: VPN Status for Gateway A (FVS318v3) and Gateway B (VPN Client)
22.23.24.25
22.23.24.25
Status of VPN tunnel
from Gateway B
Status of VPN tunnel
to Gateway B
VPN Status at Gateway A (FVS318v3)
Connection Monitor at Gateway B (remote VPN Client)
Status of VPN
tunnel to and
from Gateway A
