Reference Manual for the ProSafe VPN Firewall FVS318v3
3-2 Connecting the Firewall to the Internet
January 2005
c.
Locate the Ethernet cable (Cable 1 in the diagram) that connects your PC to the modem.
Figure 3-1: Disconnect the Ethernet cable from the computer
d.
Disconnect the cable at the computer end only, point A in the diagram.
e. Look at the label on the bottom of the VPN firewall router. Locate the Internet port.
Securely insert the Ethernet cable from your modem (Cable 1 in the diagram below) into
the Internet port of the VPN firewall router as shown in point B of the diagram.
Figure 3-2: Connect the VPN firewall router to the modem
0RGHP
&DEOH
,QWHUQHW
&RPSXWHU
A
Modem
Cable 1
Internet
Internet
port
Firewall
B

NETGEAR FVS318 - ProSafe VPN Firewall Router Specifications

General

Model	FVS318
Category	Firewall
WAN Ports	1
LAN Ports	8
VPN Pass-through	Yes
VPN Tunnels	8
SPI Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
VPN Protocol	IPSec
Compliant Standards	IEEE 802.3, IEEE 802.3u
RAM	8 MB
Flash Memory	4 MB
Power Supply	External power adapter
Network / Transport Protocol	TCP/IP, UDP
Encryption Algorithm	3DES
Features	NAT support, URL filtering, DHCP server, DoS attack prevention
Status Indicators	Port status, power
