Gear units – Operating and Assembly Instructions
12 B 1000 en-2518
CAUTION
Injury to persons
Danger of cuts from exterior edges of attachment adapters, flanges and covers.
Contact freezing with metallic components in case of low temperatures.
• In addition to personal protective equipment, wear suitable protective gloves and suitable goggles during
assembly, commissioning, inspection and maintenance, in order to prevent injuries.
It is recommended that repairs to NORD products are carried out by the NORD Service department.
Pos: 27 /A nl eitu nge n/G etr iebe /1. Hin weis e/ Wei ter e Unt erl age n @ 3 \mod_1368693112418_388.docx @ 65889 @ 2 @ 1
1.5 Other documents
Further information may be obtained from the following documents:
• Gear unit catalogues (G1000, G1012, G1014, G1035, G1050, G2000),
• Operating and maintenance instructions for the electric motor,
• if applicable, the Operating Manuals for attached or supplied options
Pos: 28 /A nl eitu nge n/G etr iebe /1. Hin weis e/E nts org ung (20 18- 07-17 13:08:4 6) @ 3\mod_1368693227234_388.docx @ 65913 @ 2 @ 1
1.6 Disposal
Observe the current local regulations. In particular, lubricants must be collected and disposed of
correctly.
Gear unit components Material
Gear wheels, shafts, rolling bearings, parallel keys, locking rings, … Steel
Gear unit housing, housing components, … Grey cast iron
Light alloy gear unit housing, light alloy gear unit housing
components, …
Aluminium
Worm gears, bushes, ... Bronze
Radial seals, sealing caps, rubber components,… Elastomers with steel
Coupling components Plastic with steel
Flat seals Asbestos-free sealing material
Gear oil Additive mineral oil
Synthetic gear oil (type plate code: CLP PG) Polyglycol-based lubricants
Cooling spiral, embedding material of the cooling spiral, screw
fittings
Copper, epoxy, yellow brass
Table 2: Disposal of materials
