3.2.1 Cable gland
The cable glands must be approved for explosion hazard areas. Unused openings must be closed with
approved blind plugs. When connecting the installation cables, the connections to the motor terminals
and to the earth lead must use U shaped bent cables placed under the relevant terminals so that the
clamping bars and the terminal bolts are equally loaded and are not deformed in any way. Alternatively,
the connections may be made with a cable lug. If increased thermal requirements are made for the
cables, these must be obtained from the information plate on the rotor.
For Sizes 63 to 132 an insulated cable lug must be used, if this is used to connect the earth lead in the
terminal box.
The nuts of the terminal board bolts must be tightened according to the following table.
Tightening torques for terminal board connections
Thread diameter M4 M5 M6 M8
Tightening torque (Nm) 1.2 2.0 3.0 6.0
Use of aluminium connecting wires is not permitted.
Pos: 77 /A nl eitu nge n/M otor en/ B10 91 D re hstro mm otor en/ 3. AT EX /K abel ver schr aub ung en_ 1 [E XN] @ 7 \mod_1431424754843_388.docx @ 218766 @ 3 @ 1
3.2.2 Cable connections
Pos: 78 /A nl eitu nge n/M otor en/ B10 91 D re hstro mm otor en/ 3. AT EX /K abel ver schr aub ung en_ 2 [E XE, EXN ] @ 7\mod_1431420767830_388.docx @ 218321 @ @ 1
If the supplied cable glands are used, cables with a circular cross-section must be used. The clamping
nuts of the cable gland must be tightened to the torque specified in the following table.
Clamping nut tightening torques
Cable gland M20x1.5 M25x1.5 M32x1.5 M40x1.5
Tightening torque (Nm) 5.0 5.0 10.0 13.5
Pos: 79 /A nl eitu nge n/M otor en/ B10 91 D re hstro mm otor en/ 3. AT EX /K abel ver schr aub ung en_ 3 [E XN] @ 1 8\mod_1496924552613_388.docx @ 2353994 @ @ 1
Use of reduction adapters according to Directive 94/9 EEC or 2014/34/EU and/or cable glands with
ignition protection class Ex ec is permissible. For this, a minimum certified temperature of 80°C is
necessary.
Pos: 80 /A nl eitu nge n/M otor en/ B10 91 D re hstro mm otor en/ 3. AT EX /K abel ver schr aub ung en_ 4 [E XE, EXN ] @ 18\ mod_1496915057687_388.docx @ 2353844 @ @ 1
When connecting, care must be taken that the permissible air gaps of at least 10 mm and the permissible
leakage tracks of at least12 mm between the electrically live components and components with the
same potential as the housing, or between live components are maintained.
Check that the terminal nuts and the screw for the earth lead are tight before closing the terminal box.
The terminal box seals and the seals of the cable glands must be correctly seated and must not be
damaged.
