NETZSCH NM125BY B.1 Series - Overview of Brake Installation for NORD ATEX Motors

3 ATEX Explosion hazard areas
B 1091 en-3118 45
Pos: 12 0 /Anlei tung en/Mo toren /B109 1 Drehs trom motor en/3. AT EX/Ü bersi cht Br emsan bau NORD ATEX- M otor en nach 9 4/9 EG @ 9\ mod_1447072875703_388.doc x @ 261699 @ 3 @ 1
3.4.6 Overview of brake installation for NORD ATEX motors
Permissible brake sizes for Category 3D motors
Size LKZ
Braking torque [Nm]
63 S, L 5
71 S, L 5
80 S, SH 5 10
80 L, LH 5 10
90 S, SH 10 20
90 L, LH 10 20
100 L, LH 20 40
100 LA, AH 20 40
112 M, SH, MH 20 40
132 S, SH 60
132 M, MH 60
132 MA 60
160 MH 100 150 250
160 LH 100 150 250
180 MH 250
180 LH 250
200 XH 250
225 SP, MP 400
250 WP 400
