Gear units – Operating and Assembly Instructions
16 B 1000 en-2518
3 Assembly instructions, storage, preparation, installation
Please observe all general safety instructions ((please see chapter 1.4 "Safety information")), the
safety information in the individual sections and the proper use ((please see chapter 1.3 "Correct
use")).
Pos: 36 /A nl eitu nge n/G etr iebe /3. Mont ag e, L ager ung , V orb erei tung , Aufst ell ung /Tr ans port des Ge trie bes (2 018-07-17 13: 39 :11) @ 3\ mod_1368705343580_388.docx @ 69456 @ 2 @ 1
3.1 Transporting the gear unit
WARNING
Hazard due to heavy loads
Severe injuries and material damage due to falling or tipping heavy loads are possible.
• Standing under the gear unit during transport is extremely dangerous.
• To prevent injury, the danger area must be generously cordoned off.
• Only transport using the eyebolts attached to the gear unit.
• No additional loads may be attached.
• If geared motors have an additional eyebolt attached to the motor, this must also be used.
• The thread of the eyebolt must be fully screwed in.
• Avoid pulling the eyebolts at an angle.
NOTICE
Gear unit damage
Damage to the gear unit due to improper use is possible.
• Prevent damage to the gear unit. Impacts to the free ends of the shafts may cause internal damage to the
gear unit.
• Use adequately dimensioned and suitable means of transportation. Lifting tackle must be designed for the
weight of the gear unit. The weight of the gear unit can be obtained from the dispatch documents.
128
