1.6 Other signs and symbols
The following states signs and symbols which are not unequivocally comprehensible. They
do not contain explanatory text and are not explained in the following chapters.
Meaning
Machine is raised by the eye hooks
– see chapter 3.19 Crane handling the machine on page 3-28
Location
On the rear chassis next to the eye hook
Meaning
Loading indications for machine.
– see chapter Strapping down the machine on page 3-30
Location
On the engine cover
Meaning
Noise levels produced by the machine.
L
WA
= sound power level
Other information – see chapter 6.11 Noise levels on page 6-4
Location
On the engine cover
Meaning
This label indicates the maximum authorised angle of inclination for driving on slopes,
whatever the position of the machine.
Location
On the rear chassis

   


Fig. 7: Eye hook label

KRRNRIFUDQH
.UDQKDNHQ
&URFKHWGHJUXH
%JHO
KDQGOH
(WULHU
+HEHEDQG
(OLQJXHHQUXEDQ
OLIWLQJEHOW
(LOOHWRQGHOHYDJH
VWRSH\H
+XE|VH
.QLFNVSHUUHHLQOHJHQ
IDVWHQDUWLFXODWLRQUHVLVWDQFH
$SSOLTXHUOHGLVSRVLWLIGHEORFDJHGHODUWLFXODWLRQ
Fig. 8: Label with indications for loading the machine

Fig. 9: Noise level label
Fig. 10: Driving on slopes
