BA 3001 En – Edition 2.0 * 345001b610.fm 6-7
Specifications
6.14 Dimensions model 3001 swivel skip
Fig. 46: Machine dimensions (model 3001S)
Main data
Model 3001S
Dead weight
2550 kg
Overall height
2670 mm
Overall height with rollbar folded down
1870 mm
Overall height without rollbar
1870 mm
Overall width
1785 mm
Ground clearance
290 mm
Wheelbase
1960 mm
Outside turning radius
3950 mm
Hill climbing ability
50 % theoretically
Safe authorised inclination
25 % in all drive positions
