BA 3001 En – Edition 2.0 * 345001b330.fm 3-23
Operation
3.13 Dumper 3001 front skip operation
Driving with a dumped-out skip is prohibited!
The working speed of the skip is set with the travel of the control lever and with
the accelerator pedal.
When dumping material into a pit, a firm resistance (beam) is required for
propping the front wheels!
☞ Never drive up to a pit only with the brakes!
Lowering the skip too rapidly and knocking it against the chassis can cause
damage and the dumper to tip over!
Position Lever Function
A
☞ Lever pushed forwards ➥ Dumping out the skip
B
☞ Lever pulled backwards ➥ Lower the skip
