BA 3001 En – Edition 2.0 * 345001b520.fm 5-15
Maintenance
Retightening the V-belt
Overtightening the V-belt can damage the V-belt, the V-belt guide and the
water pump bearing.
Avoid contact of oil, grease or similar substances with the V-belt.
☞ Check V-belt tension – see Checking V-belt tension on page 5-14
• Retighten as follows:
☞ Switch off the engine
☞ Fold the control lever base up
☞ Remove the key and carry it with you
☞ Disconnect the battery or the battery master switch
☞ Let the engine cool down
☞ Open the engine cover
☞ Slacken fastening screws 2 of alternator 3
☞ Use a suitable tool to push the alternator in the direction of arrow A until reaching the
correct V-belt tension (fig. 34)
☞ Keep the alternator in this position, and at the same time retighten fastening screws 2
☞ Check V-belt tension again and adjust it if necessary
☞ Connect the battery or the battery master switch
☞ Close the engine cover
2
3
Fig. 34: Retightening the V-belt
A
