BA 3001 En – Edition 2.0 * 345001b330.fm 3-29
Operation
Loading and transporting the machine
Safety instructions
• The transport vehicle must be of adequate size – refer to Chapter 6 “Specifications”
for the machine's dimensions and weights!
• Remove any mud, snow or ice from the tyres so that the machine can be safely driven
onto the ramps
• Secure the machine against unintentional movement
– see Parking the machine on page 3-17!
The machine must be loaded and transported properly –
Danger of accidents!
☞ It is essential that you read the safety instructions at the beginning of this
chapter and follow any other safety instructions relevant in your country!
☞ Load as follows:
• Secure the transport vehicle with chocks to prevent it from rolling
• Place the access ramps at the smallest possible angle. Make sure the grade does not
exceed 17° (30%). Use access ramps with an antiskid surface only.
• Make sure the loading area is clear and access to it is not obstructed –
e.g. by superstructures
• Make sure the ramps and the tyres of the dumper are free of oil, grease and ice
• Start the engine of the dumper
• Lower the skip of the dumper
• Carefully reverse the dumper onto the middle of the transport vehicle
• Stop and park the machine
The manufacturer's warranty shall not apply to accidents or damage caused by
loading or transporting the excavator.
