Neuson 3001 - Steering System; Work Hydraulics; Skip; Drive Specifications

6-2 BA 3001 En – Edition 2.0 * * 345001b610.fm
Specifications
6.5 Steering system
6.6 Work hydraulics
6.7 Skip
6.8 Drive specifications
Steering system
Model 3001
Design
Hydrostatic
Steering mode
Chassis articulation steering
Work hydraulics
Model 3001
Hydraulic pump displacement
16.2 cm³/rev
Hydraulic pump flow rate
45 l/min
Max. service pressure
175 bar
Secondary pressure limiting for offset ram
160 bar
Hydraulic tank capacity
48 l
Steering system
150 bar
Skip
Model 3001 F Model 3001S
Skip capacity
1500 l struck 1300 l struck
1850 l heaped 1750 l heaped
1160 l liquid capacity 900 l liquid capacity
Payload
3000 kg
Swivel angle
- 180 – 217°
Steering system
Model 3001 F Model 3001S
Drive speed I
0 – 7 kph
Drive speed II
0 – 22 kph
Articulation
+/- 37°
Oscillation
+/- 15°
Outside turning radius
4000 mm 3950 mm
Hill climbing ability
50 % (theoretically)
Safe authorised inclination
25 % in all drive positions left/right
