BA 3001 En – Edition 2.0 * 345001b320.fm 3-11
Operation
52 Not assigned
48 Parking brake telltale (red)
Comes on if the parking brake is applied!
In this case:
☞ Actuate lever 28 to release the parking brake
43 High beam telltale (blue)
Comes on if high beam is on.
Make sure no other road users are dazzled during road travel!
☞ Switch on low beam
51 Turn indicator telltale (green)
Flashes if the turn indicator is switched on.
41 Hour meter
Counts the engine service hours with the engine running.
53 Fuel level indicator
Refuel immediately if the fuel level indicator reaches minimum. Otherwise the fuel system
must be bled if it is run dry.
