Nexo LS18

Page 34/106 GEO S12 HARDWARE SETUP PROCEDURE
8.3 GEO S12 in fixed installations
8.3.1 Fixed installation Accessories and kits
Accessories are:
 Bumper for Geo S12 & LS18 (GPI-BUMPER)
 “U” Bracket (VNI-UBRK12)
 “L” Bracket for cable suspension (VNI-LBRK)
 “U” Bracket for rigid suspension (VNI-ABRK)
 Connecting Plates / range : 0.20° - 3.15° (GPI-ANPL1)
 Connecting Plates / range : 5.00° - 10.0° (GPI-ANPL2)
 Connecting Plates / range : 16.0° - 30.0° (GPI-ANPL3)
 Counter-Plates for LS18 (LSI-CPLA)
Please refer to section 11.5 of this manual for more information of above references.
IMPORTANT
In order to prevent screws from getting loose in fixed installations, we deliver thread lock
coated screws, if not use blocking liquid LOCTITE
TM
243 or equivalent for all screws used
with GEO S12 & LS18 fixed installation accessories.
LOCTITE
TM
243 is available at NEXO or at your local distributor upon request.
GPI-BUMPER VNI-UBRK12 VNI-LBRK VNI-ABRK
GPI-ANPL1 GPI-ANPL2 GPI-ANPL3
