Alternative Procedure (“Walder” procedure)
Below described procedure required 2 additional 8x20 quick release pins (BLGEOS)
 Split the GPT-PSBRK side plates by removing screws and bolt;
 Slide GPT-PSBRK lower half-plates into lower GEO S12 connecting plate oblong holes;
 Lock safety pins into lower GEO S12 connecting plate;
 Position “U” bracket over these lower half plates; align centre holes;
 Insert adjustment handles, adjust vertical angle and tight the handles to prevent GEO S12
from rotating around “U” bracket;
 Lift assembly on Wind Up stand or on LS18 with PLSTD pole stand.
 Slide GPT-PSBRK upper half-plates into upper GEO S12 connecting plate oblong holes;
 Lock safety pins into upper GEO S12 connecting plate;
 Lift upper GEO S12 on top of lower one, and connect them together by inserting 8x20
quick release pins in articulation holes;
 Adjust inter-cabinet angle and lock to required angle value with quick release pins.
IMPORTANT
Ensure that safety pins are properly locked into GEO S12 connecting panels.
