Nexo LS18

Page 70/106 GEO S12 HARDWARE SETUP PROCEDURE
 Connect bottom LS18 or GEO S12 to GPT-GSTK Ground stacking device with 4 8x20
quick release pins;
 Connect second LS18 or Geo S12 with X-Bow front articulation holes and rear link bars
and ensure quick release pins are properly locked;
 Repeat above steps for subsequent cabinets
