3.2.5 – FL200 ashing light (optional)
• The ashing light must be positioned near the door in
a clearly visible position. It can be fasted to a horizontal or
vertical surface. • ForconnectiontotheFlashterminal,no pola-
rityneedstobeobserved;insteadforconnectionoftheshielded
aerialcable,itisnecessarytoconnectthecableandsheathas
showninFig. 24(06)andFig. 29.
Choosethemostsuitablepositioninwhichtoinstalltheashing
light:itmustbepositionednearthedoorinaclearlyvisibleposi-
tion.Itcanbefastedtoahorizontalorverticalsurface.
Ø = 6 mm
x4
05. B
Ø = 6 mm
x4
05. A
2
1
01. 02. 03. 04.
(aerial)(flash)
2
1
06. 07.
08. 09.
24
FortheinstallationprocedureseeFig. 24.
