English – 21
Parameter No.
Parameter name
Unit
Minimum
value
Maximum
value
Default value
STD
Default value
EE_1
Default value
EE_2/EE_3
MLS
ELS
From version
46
Trafc light warning activation options
0 = Warning only if door is at upper limit stop
1 = Warning after closing command regardless of door position
Num. 0 1 0 0 0 x x 1.44
High speed doors / Inverter
50
Brake control options (solely for EE_0 and EE_1 deletion)
0 = No brake connected
1 = Brake connected
Num. 0 1 1 1 - x x 0.33
51
Brake activation delay during opening manoeuvre
(solely for EE_0 and EE_1 deletion)
10 ms 0 50 12 10 - x x 0.33
52
Brake deactivation delay during opening manoeuvre
(solely for EE_0 and EE_1 deletion)
10 ms 0 50 4 4 - x x 0.33
53
Brake activation delay during closing manoeuvre
(solely for EE_0 and EE_1 deletion)
10 ms 0 50 12 10 - x x 0.33
54
Brake deactivation delay during closing manoeuvre
(solely for EE_0 and EE_1 deletion)
10 ms 0 50 4 4 - x x 0.33
55 Duration of slow speed (or creep) for reaching upper limit stop 10 ms 20 250 70 70 70 - x 1.37
56 Duration of slow speed (or creep) for reaching lower limit stop 10 ms 10 250 15 15 15 - x 1.37
57
Brake activation below minimum speed detected by encoder (solely for
EE_0 and EE_1 deletion)
Incr 0 50 0 10 - - x 0.37
58 Brake activation delay in case of emergency stop ms 0 500 0 10 10 - x 0.37
59
Range of fast closing distance calculated from upper limit stop
To set, press and hold the STOP button for about 2 seconds
Incr 0 5000 0 0 0 - x 1.08
Time monitoring
60
Modes for monitoring manoeuvre run time
0 = Monitoring disabled or active for tubular motors
1 = Automatic mode (only with electronic limit switch)
2 = Manual mode
3 = Manual mode, including minimum time monitoring (only for inverters)
Num. 0 4 2 3 3 x x 0.33
61 Maximum run time (full manoeuvre) Sec. 0 240 60 10 10 x x 0.33
62 Maximum run time (partial opening) Sec. 0 240 60 6 6 x x 0.33
63 Minimum run time (full manoeuvre) for motors with inverter 1/10 s 0 240 0 20 20 x x 0.33
64 Manoeuvre average run time 1/10 s 0 - - - - x x 0.33
65 Last run time performed by door 1/10 s 0 - - - - x x 0.33
Door control
70
Door operation selection
0 = Standard operation (single-phase and three-phase motors)
1 = Motor operation with Nice inverters without label
2 = Not used
3 = Motor operation with Nice inverters with label EE_2 and EE_3
4 = Tubular motor operation
Num. 0 4 0 1 3
x
x
x
x
0.33
1.32
71 Main contactor activation delay ms 0 250 0 0 0 x x 0.33
72 Direction relay deactivation delay ms 15 250 23 23 23 x x 0.33
73 Rotation direction inversion delay 10 ms 6 250 70 70 70 x x 0.33
74 Time delay for inverting run direction following safety edge trigger 10 ms 3 250 4 4 4 x x 0.33
75
Run direction (can also be changed with DIP switches 3 and 4 ON)
0 = No change to motor direction of rotation
1 = Change motor direction of rotation
Num. 0 1 0 0 0 x x 1.53
76 Motor starting capacitor activation time (single-phase motors only) 1/10 s 0 50 15 0 0 x x 0.50
77 Auto safety test delay 10 ms 10 250 25 25 25 x x 0.63
