Nice D-PRO AUTOMATIC NDCC1000 - Page 24

EN
24 – English
Parameter No.
Parameter name
Unit
Minimum
value
Maximum
value
Default value
STD
Default value
EE_1
Default value
EE_2/EE_3
MLS
ELS
From version
112
Options for relay 1 (X3 pins 7-8-9)
Num. 0 25 0 0 0
x x
0.33
0 = Trafc light manoeuvre indicator ashing
1 = Trafc light manoeuvre indicator on steady
2 = Trafc light manoeuvre indicator ashing but only during manoeuvre
(off when door stationary)
x x 1.76
3 = Trafc light manoeuvre indicator on steady but only during manoeuvre
(off when door stationary)
10 - 25 = as for P110
Options for NDA030 board inputs
120
Input 1 option
0 = Secondary photocell
10 - 23 = as for P100
Num. 0 23 0 0 0 x x 0.80
121
Input 2 option
0 = Open from outside
10 - 23 = as for P100
Num. 0 23 0 0 0 x x 0.80
122
Input 3 option
0 = Enable partial opening
10 - 23 = as for P100
Num. 0 23 0 0 0 x x 0.80
123
Input 4 option
0 = Enable automatic closing
10 - 23 = as for P100
Num. 0 23 0 0 0 x x 0.80
124
Input 5 option
0 = Enable man-present movement mode
10 - 23 = as for P100
Num. 0 23 0 0 0 x x 0.80
125
Input 6 option
0 = Fire detection - close door
10 - 23 = as for P100
Num. 0 23 0 0 0 x x 0.80
Options for NDA030 board outputs
130
Relay output 1 options (NO)
0 = Door open signal
10 - 25 = as for P110
Num. 0 25 0 0 0 x x 0.80
131
Relay output 2 options (NO)
0 = Door closed signal
10 - 25 = as for P110
Num. 0 25 0 0 0 x x 0.80
132
Relay output 3 options (NO)
0 = No active function by default
1 = Test of rst set of photocells
10 - 25 = as for P110
Num. 0 25 0 0 0 x x 0.80
133
Relay output 4 options (NO)
0 = No active function by default
1 = Test of second set of photocells
10 - 25 = as for P110
Num. 0 25 0 0 0 x x 0.80
Additional parameters
140 Short reverse time following safety edge trigger (see also parameter P105)
1/10
Sec
0 250 0 0 0 x x 1.70
