EN
English – 23
Parameter No.
Parameter name
Unit
Minimum
value
Maximum
value
Default value
STD
Default value
EE_1
Default value
EE_2/EE_3
MLS
ELS
From version
105
Options for safety edge and man-present mode (Connector X5 - J32)
0 = Optical or resistive safety edge connected
1 = Pneumatic safety edge connected
2 = Electrical safety edge connected, but only with inversion
3 = Pneumatic edge connected, but only with inversion
4 = No safety edge connected - close only when man present
5 = No safety edge connected - close also possible in industrial mode
(semi-automatic opening and closure when man present)
6 = No safety edge connected - open and close always when man
present
7 = SBA sensor connected
8 = Beam safety edge (dipped beam) - within the pre-limit, edge activation
ignored
Num. 0 12 0 0 0
x x 0.33
9 = Safety edge activation works in both directions with a short reverse
(sliding gates)
x x 0.96
10 = Electrical safety edge connected - stop without reverse, open only
when man present
x x 1.16
11 = Electrical safety edge connected - 0.5s reverse, open only when man
present
x x 1.30
12 = Electrical safety edge connected - full door opening, close when man
present
x x 1.31
106
Radio receiver options
0 = No radio receiver connected
1 = Normal operations as per command (OPEN - STOP - CLOSE)
2 = Open from inside
3 = Open from outside
Num. 0 4 0 0 0
x x 0.33
4 = Apartment-block step-by-step x x 1.29
107
Options for front panel buttons
0 = Normal operation
1 = Front panel buttons locked
Num. 0 1 0 0 0 x x 0.53
Options for outputs
110
Options for relay 3 (X3 pins 1-2-3)
0 = Door closed signal
10 = Door status signal via internal red/green trafc light
11 = Door status signal via external red/green trafc light
12 = Door movement status signal - light on/off
13 = Static signal in case of error
14 = Close door bolt (see also parameter P84)
15 = Open door bolt (see also parameter P85)
16 = Signal when moving door is detected
17 = Optical (or light) grid test
18 = Alarm when door stays open for more than 30s
19 = Radio safety edge test
20 = Air curtain activation (see also parameter P45)
Num. 0 25 0 0 0
x x 0.33
21 = Connection of a relay to control an additional brake 1.12
22 = Power transmission activation (for loading radio safety edges. See
also parameters P88-P89)
x x 1.42
23 = Fire alarm x x 1.46
24 = Door opening signal x x 1.49
25 = Door closing signal x x 1.49
111
Options for relay 2 (X3 pins 4-5-6)
0 = Door open signal
10 - 25 = as for P110
Num. 0 25 0 0 0 x x 0.33
